TDI VE what about exhaust manifold which is the best
by
jabcok20
on 17 Feb, 2013 13:00
-
Hello i search info for the best exhaust manifold for my tdi afn. By few days i want to put gtb1756vk turbo. So for 220HP is it worth to change ori manifold from b5 AWX to other better manifold. I saw that people put in this from old diesel ( with few changes ) or from 1.6td. Is it worth to put one of those?
Or waht about manifoldfrom vw sharan tdi
Uploaded with
ImageShack.us
-
#1
by
G60ING
on 18 Feb, 2013 08:03
-
I've thought about a Sharon manifold but with the location of the turbo changing you would need new oil lines, turbo inlet piping and downpipe.
-
#2
by
Henk
on 23 Feb, 2013 03:23
-
interesting flowing on that, looks better than standard.
I just have a normal manifold with the 4 bolt fitting at 45degrees to the head, i'm sure it'll be good enough for both our needs, plus would you be able to fit that manifold in d'you think?
-
#3
by
R.O.R-2.0
on 01 Mar, 2013 15:22
-
interesting flowing on that, looks better than standard.
I just have a normal manifold with the 4 bolt fitting at 45degrees to the head, i'm sure it'll be good enough for both our needs, plus would you be able to fit that manifold in d'you think?
this is what i did for a high-flow manifold..
turbo header!!
StreetToys 2000 builds them.. this is one of his old "space saver" manifolds, they are not produced like this any longer.
they are expensive, but they are awesome as well..
-
#4
by
G60ING
on 01 Mar, 2013 20:55
-
interesting flowing on that, looks better than standard.
I just have a normal manifold with the 4 bolt fitting at 45degrees to the head, i'm sure it'll be good enough for both our needs, plus would you be able to fit that manifold in d'you think?
Good point my b5 manifold barely fits in my my corrado
-
#5
by
vanbcguy
on 01 Mar, 2013 22:02
-
I'm eagerly watching this thread. Trying to decide what I want to do for a manifold too. I've seen a few generic 8v T3 manifolds but it is hard to know what will fit!
Sent from my HTC One X using Tapatalk 2
-
#6
by
R.O.R-2.0
on 05 Mar, 2013 15:10
-
I'm eagerly watching this thread. Trying to decide what I want to do for a manifold too. I've seen a few generic 8v T3 manifolds but it is hard to know what will fit!
Sent from my HTC One X using Tapatalk 2
the generic ones are pretty useless...
-
#7
by
vanbcguy
on 05 Mar, 2013 15:29
-
I'm eagerly watching this thread. Trying to decide what I want to do for a manifold too. I've seen a few generic 8v T3 manifolds but it is hard to know what will fit!
Sent from my HTC One X using Tapatalk 2
the generic ones are pretty useless...
Useless how? Useless as in they don't physically fit? Useless as in they have poor flow characteristics?
The stock AHU manifold doesn't look particularly good:
...whereas a generic 8V T25 manifold looks like it'd flow a lot nicer:
...though I kind of suspect the turbo would be getting quite intimate with the firewall...
-
#8
by
MJF
on 05 Mar, 2013 17:49
-
That generic T3 manifold has large open plenum which causes slow spooling. Stock AFN manifold is pretty good one.
-
#9
by
R.O.R-2.0
on 06 Mar, 2013 23:20
-
That generic T3 manifold has large open plenum which causes slow spooling. Stock AFN manifold is pretty good one.
it also has a big restriction in the runners for #1 & #2 cyl..
HUGE hump blocking a good 20-30% of the runners.. ill take a pic some day..
yes, they have a large internal volume, making spool times slower..
-
#10
by
vanbcguy
on 07 Mar, 2013 12:50
-
-
#11
by
R.O.R-2.0
on 14 Mar, 2013 22:05
-
both manifolds pictured are NICE pieces..
-
#12
by
vanbcguy
on 14 Mar, 2013 22:48
-
They are both about $250. I'm probably going to go with the top one myself...
Sent from my HTC One X using Tapatalk 2
-
#13
by
R.O.R-2.0
on 19 Mar, 2013 17:49
-
They are both about $250. I'm probably going to go with the top one myself...
Sent from my HTC One X using Tapatalk 2
bottom one is set up for an external wastegate, so if you run the top one, make sure you have an integral wastegate..
-
#14
by
vanbcguy
on 19 Mar, 2013 19:36
-
Actually both have an external wastegate flange. The PDF files show the full dimensional drawings and things.
The turbo I'm planning on does have an internal wastegate either way though. The one problem I need to figure out is it has studs on two of the manifold flange bolts which may be a challenge with either of these manifolds.
Sent from my HTC One X using Tapatalk 2
